2xRCA -> TOSL, COAX audio signal converter
SKU:ACON2508BK
Manufacturer:Nedis
Image is for illustrative purposes only
This analog to digital audio (ADC) converter is suitable to convert an analog audio signal to a digital audio signal. Thanks to this converter you can connect a device with analog Tulp stereo 2x RCA output to an amplifier / receiver with optical Toslink or coaxial RCA (S/P-DIF) input.
• 1-way conversion - Converts analogue stereo audio signals to Toslink or RCA.
• Amplifies digital audio signals - Keeping the audio signal in the digital domain virtually all the way to the connected device
• Compact design - For easy installation and use
• 1-way conversion - Converts analogue stereo audio signals to Toslink or RCA.
• Amplifies digital audio signals - Keeping the audio signal in the digital domain virtually all the way to the connected device
• Compact design - For easy installation and use
Data transfer direction: 2-way
Colour: Black
Material: ABS
Power cable side A: USB
Input current: 0.6 A
Power source type: USB Powered
Power cable length: 1.80 m
Power consumption in standby mode: 1.0 W
Width: 57.0 mm
Device type: Digital Audio Converter
Power on LED indicator: Yes
Power switch: Yes
Supported bitrates: 96 kHz 24-bit
Supported formats: PCM
Controlling method: Manual
Connection output: 1x TosLink Female, 1x S/PDIF (RCA) Female
Connection input: 2x RCA Male
Height: 23.0 mm
Length: 84.0 mm
Depth: 50.5 mm
Device power input connection(s): DC 9 x 5.5 mm
Power cable side B: DC 9 x 5.5 mm
Power consumption in operating mode: 2.0 W
Weight: 44.0 g
Input voltage: 5.0 VDC
Colour: Black
Material: ABS
Power cable side A: USB
Input current: 0.6 A
Power source type: USB Powered
Power cable length: 1.80 m
Power consumption in standby mode: 1.0 W
Width: 57.0 mm
Device type: Digital Audio Converter
Power on LED indicator: Yes
Power switch: Yes
Supported bitrates: 96 kHz 24-bit
Supported formats: PCM
Controlling method: Manual
Connection output: 1x TosLink Female, 1x S/PDIF (RCA) Female
Connection input: 2x RCA Male
Height: 23.0 mm
Length: 84.0 mm
Depth: 50.5 mm
Device power input connection(s): DC 9 x 5.5 mm
Power cable side B: DC 9 x 5.5 mm
Power consumption in operating mode: 2.0 W
Weight: 44.0 g
Input voltage: 5.0 VDC
-
