TurretCam HL (5 Mp/2.8 mm)
SKU:126260.197.BL1
Manufacturer:Ajax Systems Inc
New
Image is for illustrative purposes only
Product Overview
The TurretCam HL (5 Mp/2.8 mm) is a professional wired IP camera designed for high-definition surveillance within the Ajax ecosystem, featuring intelligent object recognition and versatile hybrid lighting.
Key Features
- High-resolution 5 MP imaging with a 110° wide-angle lens for comprehensive area coverage.
- Smart hybrid lighting system that utilizes infrared in standby and switches to white LEDs upon motion detection for full-color video and active deterrence.
- True WDR technology to maintain image clarity and detail in high-contrast lighting environments.
- Seamless integration via the high-speed JetSparrow protocol for efficient data transmission.
- Flexible storage support for local microSD cards or connection to a dedicated NVR.
- Robust housing rated IP65 for weather resistance and IK08 for protection against mechanical impact.
Applications
With its durable construction and advanced lighting capabilities, this camera is ideal for professional security setups in residential or commercial properties requiring reliable outdoor and indoor monitoring.
The TurretCam HL (5 Mp/2.8 mm) is a professional wired IP camera designed for high-definition surveillance within the Ajax ecosystem, featuring intelligent object recognition and versatile hybrid lighting.
Key Features
- High-resolution 5 MP imaging with a 110° wide-angle lens for comprehensive area coverage.
- Smart hybrid lighting system that utilizes infrared in standby and switches to white LEDs upon motion detection for full-color video and active deterrence.
- True WDR technology to maintain image clarity and detail in high-contrast lighting environments.
- Seamless integration via the high-speed JetSparrow protocol for efficient data transmission.
- Flexible storage support for local microSD cards or connection to a dedicated NVR.
- Robust housing rated IP65 for weather resistance and IK08 for protection against mechanical impact.
Applications
With its durable construction and advanced lighting capabilities, this camera is ideal for professional security setups in residential or commercial properties requiring reliable outdoor and indoor monitoring.
AI Analytics: Recognition of people, animals, and transport
Audio: Built-in digital microphone
Backlight: Hybrid (IR and white light) up to 50 m
Dimensions: 103 × 98 × 98 mm
Dynamic Range: True WDR (120 dB)
Frame Rate: up to 25 FPS
Lens: 2.8 mm, fixed
Network Interface: RJ-45 (10/100 Mbps)
Operating Temperature: -30 °C to +60 °C
Power: PoE (802.3at/af) or 12 V DC ± 20%
Power Consumption: up to 7.2 W (PoE), up to 6.3 W (12 V)
Protection Class: IP65, IK08
Protocols: JetSparrow (proprietary), ONVIF (Profile S/T), RTSP
Resolution: 5 MP (2880 × 1620)
Sensor: 1/2.8" CMOS
Storage: microSD up to 256 GB (Class V30+), Ajax NVR
Video Codecs: H.265, H.264
Viewing Angle: Horizontal: 110°, Vertical: 58°, Diagonal: 131°
Weight: 475 g
Audio: Built-in digital microphone
Backlight: Hybrid (IR and white light) up to 50 m
Dimensions: 103 × 98 × 98 mm
Dynamic Range: True WDR (120 dB)
Frame Rate: up to 25 FPS
Lens: 2.8 mm, fixed
Network Interface: RJ-45 (10/100 Mbps)
Operating Temperature: -30 °C to +60 °C
Power: PoE (802.3at/af) or 12 V DC ± 20%
Power Consumption: up to 7.2 W (PoE), up to 6.3 W (12 V)
Protection Class: IP65, IK08
Protocols: JetSparrow (proprietary), ONVIF (Profile S/T), RTSP
Resolution: 5 MP (2880 × 1620)
Sensor: 1/2.8" CMOS
Storage: microSD up to 256 GB (Class V30+), Ajax NVR
Video Codecs: H.265, H.264
Viewing Angle: Horizontal: 110°, Vertical: 58°, Diagonal: 131°
Weight: 475 g
