SKU:AKX00066-TT
New
Image is for illustrative purposes only
Arduino Alvik is a versatile educational robot designed for learning programming and robotics across various skill levels. Powered by the Arduino Nano ESP32, it supports block-based coding, MicroPython, and the Arduino language. The curriculum and lessons are aligned with CSTA and NGSS standards for educational environments.
The robot features a comprehensive suite of integrated sensors, including a Time of Flight (ToF) distance sensor with a range up to 350 cm, an RGB color sensor, a 6-axis gyroscope and accelerometer, and a line-following array. These capabilities allow for projects involving obstacle avoidance, color recognition, and autonomous navigation.
For customization and expansion, Alvik includes LEGO Technic connectors, M3 screw mounts, and specialized ports for I2C Grove, I2C Qwiic, and servo motors. Its compact design is powered by a rechargeable and replaceable 18650 Li-Ion battery via a USB-C port, ensuring long-term usability in classrooms, makerspaces, or home environments.
The robot features a comprehensive suite of integrated sensors, including a Time of Flight (ToF) distance sensor with a range up to 350 cm, an RGB color sensor, a 6-axis gyroscope and accelerometer, and a line-following array. These capabilities allow for projects involving obstacle avoidance, color recognition, and autonomous navigation.
For customization and expansion, Alvik includes LEGO Technic connectors, M3 screw mounts, and specialized ports for I2C Grove, I2C Qwiic, and servo motors. Its compact design is powered by a rechargeable and replaceable 18650 Li-Ion battery via a USB-C port, ensuring long-term usability in classrooms, makerspaces, or home environments.
Main controller: Arduino Nano ESP32
Microcontroller: u-blox NORA-W106 (ESP32-S3)
Processor speed: up to 240 MHz
Memory: 8 MB RAM, 384 kB ROM, 512 kB SRAM
External flash: 16 MB External FLASH
On-board core: STM32 Arm Cortex-M4 32 Bit
Power supply: Nano ESP-32 USB-C rechargeable and replaceable 18650 Li-Ion battery (included)
Programming languages: MicroPython, Arduino, block-based programming
Connectivity: Wi-Fi, Bluetooth LE
Inputs: Time of Flight Distance Sensor (up to 350 cm), RGB Color Sensor, 6-axis Gyroscope-Accelerometer, Line follower Array (x3), Touchable Buttons (x7)
Outputs: 2x RGB LEDs, 6V Motors (no-load speed 96 rpm, no-load current 70 mA)
Extensions: 4x LEGO Technic connectors, 8x M3 screw connectors, Servo motor port, I2C Grove, I2C Qwiic
Conformities: UKCA, CE, RoHS
Weight: 0.41 kg
In the box: Arduino Alvik robot
Arduino Nano ESP32 controller
18650 Li-Ion battery
Microcontroller: u-blox NORA-W106 (ESP32-S3)
Processor speed: up to 240 MHz
Memory: 8 MB RAM, 384 kB ROM, 512 kB SRAM
External flash: 16 MB External FLASH
On-board core: STM32 Arm Cortex-M4 32 Bit
Power supply: Nano ESP-32 USB-C rechargeable and replaceable 18650 Li-Ion battery (included)
Programming languages: MicroPython, Arduino, block-based programming
Connectivity: Wi-Fi, Bluetooth LE
Inputs: Time of Flight Distance Sensor (up to 350 cm), RGB Color Sensor, 6-axis Gyroscope-Accelerometer, Line follower Array (x3), Touchable Buttons (x7)
Outputs: 2x RGB LEDs, 6V Motors (no-load speed 96 rpm, no-load current 70 mA)
Extensions: 4x LEGO Technic connectors, 8x M3 screw connectors, Servo motor port, I2C Grove, I2C Qwiic
Conformities: UKCA, CE, RoHS
Weight: 0.41 kg
In the box: Arduino Alvik robot
Arduino Nano ESP32 controller
18650 Li-Ion battery
