SKU:ACON3415AT
New
Image is for illustrative purposes only
The Nedis ACON3415AT is a compact digital audio converter designed to extract audio signals from an HDMI stream, including eARC support, for output to external sound systems.
Key Features
- Extracts audio from HDMI and eARC sources to analog RCA and 3.5 mm interfaces
- Supports high-definition audio with sampling rates up to 192 kHz and 24-bit depth
- Enables seamless video pass-through to a TV or monitor without signal interference
- Compact and durable housing constructed from ABS plastic
- Powered via a standard Micro USB port for convenient setup
Applications
This device is ideal for users looking to connect modern displays to external amplifiers or speakers. Its support for eARC and high-resolution audio makes it a reliable solution for integrating legacy analog audio equipment into a contemporary home entertainment setup without compromising video quality.
Key Features
- Extracts audio from HDMI and eARC sources to analog RCA and 3.5 mm interfaces
- Supports high-definition audio with sampling rates up to 192 kHz and 24-bit depth
- Enables seamless video pass-through to a TV or monitor without signal interference
- Compact and durable housing constructed from ABS plastic
- Powered via a standard Micro USB port for convenient setup
Applications
This device is ideal for users looking to connect modern displays to external amplifiers or speakers. Its support for eARC and high-resolution audio makes it a reliable solution for integrating legacy analog audio equipment into a contemporary home entertainment setup without compromising video quality.
Weight: 23 g
Input: 1x HDMI Input (eARC support)
Output: 2x RCA Female, 1x 3.5 mm Female
Power indicator: LED
Housing material: ABS
Control method: Automatic
Transmission direction: 1-way
Power supply: 5 VDC / 0.6 A
Supported audio formats: PCM, Dolby Atmos, Dolby TrueHD, DTS:X, DTS Master
Supported sample rates: 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
Dimensions: 52 x 52 x 22 mm
Bit depth: 24-bit
Power connector: USB Micro B Female
Device type: Digital Audio Converter
Color: Anthracite
Input: 1x HDMI Input (eARC support)
Output: 2x RCA Female, 1x 3.5 mm Female
Power indicator: LED
Housing material: ABS
Control method: Automatic
Transmission direction: 1-way
Power supply: 5 VDC / 0.6 A
Supported audio formats: PCM, Dolby Atmos, Dolby TrueHD, DTS:X, DTS Master
Supported sample rates: 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
Dimensions: 52 x 52 x 22 mm
Bit depth: 24-bit
Power connector: USB Micro B Female
Device type: Digital Audio Converter
Color: Anthracite
-
