ESP32-C3-MINI-1
SKU:OKY2252-4C
Manufacturer:Okystar
Image is for illustrative purposes only
The ESP32-C3-MINI-1 is a compact, general-purpose module providing both Wi-Fi and Bluetooth 5 (LE) connectivity. It is built around a 32-bit single-core RISC-V processor, making it a powerful and efficient core for a wide range of embedded projects.
Key Features
- Processor: Powered by a 32-bit single-core RISC-V CPU (ESP32-C3FH4 or ESP32-C3FN4 chip).
- Wireless Connectivity: Supports both Wi-Fi (IEEE 802.11 b/g/n) and Bluetooth 5 (Low Energy).
- Memory: Equipped with 4 MB of integrated flash memory for application code and data storage.
- Interfaces: Offers a rich set of peripheral interfaces, including GPIO, SPI, I2C, and UART, for flexible hardware integration.
Applications
Its small size and versatile feature set make this module an excellent choice for developing connected devices. It is well-suited for applications in smart home automation, industrial control systems, healthcare monitoring, and various consumer electronics.
Key Features
- Processor: Powered by a 32-bit single-core RISC-V CPU (ESP32-C3FH4 or ESP32-C3FN4 chip).
- Wireless Connectivity: Supports both Wi-Fi (IEEE 802.11 b/g/n) and Bluetooth 5 (Low Energy).
- Memory: Equipped with 4 MB of integrated flash memory for application code and data storage.
- Interfaces: Offers a rich set of peripheral interfaces, including GPIO, SPI, I2C, and UART, for flexible hardware integration.
Applications
Its small size and versatile feature set make this module an excellent choice for developing connected devices. It is well-suited for applications in smart home automation, industrial control systems, healthcare monitoring, and various consumer electronics.
Antenna: On-board PCB antenna
Bluetooth: Bluetooth LE: Bluetooth 5, Bluetooth mesh
Interfaces: GPIO, SPI, UART, I2C, I2S, remote control peripheral, LED PWM controller, general DMA controller, TWAI® controller, USB Serial/JTAG controller, temperature sensor, ADC
Memory: 384 KB ROM, 400 KB SRAM (16 KB for cache), 8 KB SRAM in RTC, 4 MB embedded flash
Operating Voltage: 3.0 ~ 3.6 V
Processor: 32-bit RISC-V single-core processor, up to 160 MHz
Wi-Fi: IEEE 802.11 b/g/n-compliant, 2.4 GHz band, 20 MHz and 40 MHz bandwidth, up to 150 Mbps
Bluetooth: Bluetooth LE: Bluetooth 5, Bluetooth mesh
Interfaces: GPIO, SPI, UART, I2C, I2S, remote control peripheral, LED PWM controller, general DMA controller, TWAI® controller, USB Serial/JTAG controller, temperature sensor, ADC
Memory: 384 KB ROM, 400 KB SRAM (16 KB for cache), 8 KB SRAM in RTC, 4 MB embedded flash
Operating Voltage: 3.0 ~ 3.6 V
Processor: 32-bit RISC-V single-core processor, up to 160 MHz
Wi-Fi: IEEE 802.11 b/g/n-compliant, 2.4 GHz band, 20 MHz and 40 MHz bandwidth, up to 150 Mbps
-
