8 MP AcuSense Powered-by-Darkfighter Fixed Bullet Network Camera
SKU:DS-2CD2T86G2H-4I2.8B
Manufacturer:Hikvision
New
Image is for illustrative purposes only
This Hikvision DS-2CD2T86G2H-4I2.8B is a network bullet camera designed for high-quality surveillance with advanced features for clear imaging and smart detection.
Key Features
- Provides high-quality 8 MP resolution imaging.
- Powered-by-Darkfighter technology ensures excellent performance in low-light conditions.
- Offers clear imaging against strong backlight with 120 dB WDR.
- Efficient H.265+ compression saves bandwidth and storage.
- AcuSense technology with deep learning focuses on classifying people and vehicles, significantly reducing false alarms.
- Features a fixed 2.8 mm lens.
- Provides IR illumination up to 80 meters range.
- Supports microSD card storage up to 512 GB.
- Rated IP67 for protection against water and dust.
Applications
Its robust IP67 rating makes this camera suitable for outdoor use. The combination of high resolution, low-light capability, and AcuSense smart detection makes it ideal for surveillance scenarios requiring accurate target classification and reduced false alarms in various lighting and environmental conditions.
Key Features
- Provides high-quality 8 MP resolution imaging.
- Powered-by-Darkfighter technology ensures excellent performance in low-light conditions.
- Offers clear imaging against strong backlight with 120 dB WDR.
- Efficient H.265+ compression saves bandwidth and storage.
- AcuSense technology with deep learning focuses on classifying people and vehicles, significantly reducing false alarms.
- Features a fixed 2.8 mm lens.
- Provides IR illumination up to 80 meters range.
- Supports microSD card storage up to 512 GB.
- Rated IP67 for protection against water and dust.
Applications
Its robust IP67 rating makes this camera suitable for outdoor use. The combination of high resolution, low-light capability, and AcuSense smart detection makes it ideal for surveillance scenarios requiring accurate target classification and reduced false alarms in various lighting and environmental conditions.
Image Sensor: 1/1.8" Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Min. Illumination: Color: 0.0008 Lux @ (F1.0, AGC ON), B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Lens Type: Fixed focal lens, 2.8 mm
Focal Length & FOV (2.8 mm): horizontal FOV 105.1°, vertical FOV 54.8°, diagonal FOV 128.2°
Lens Mount: M16
Aperture: F1.0
Supplement Light Type: IR
Supplement Light Range: Up to 80 m (4I model)
IR Wavelength: 850 nm
Video Compression (Main Stream): H.265/H.264/H.264+/H.265+
Video Compression (Sub-stream): H.265/H.264/MJPEG
Video Compression (Third stream): H.265/H.264
Main Stream Frame Rate (50 Hz): 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Main Stream Frame Rate (60 Hz): 24 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream Frame Rate (50 Hz): 25 fps (1280 × 720, 640 × 480, 640 × 360)
Sub-Stream Frame Rate (60 Hz): 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream Frame Rate (50 Hz): 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Third Stream Frame Rate (60 Hz): 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Audio: Built-in microphone (DS-2CD2T86G2H-IS2U/S model, check specific SKU)
Power Method: 12 VDC, PoE (802.3af)
Max Power Consumption: 12 W (PoE), 10 W (12 VDC)
Ingress Protection: IP67
Dimensions: 286.7 × 93.3 × 91.2 mm
Weight: Approx. 1180 g
Max. Resolution: 3840 × 2160
Min. Illumination: Color: 0.0008 Lux @ (F1.0, AGC ON), B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Lens Type: Fixed focal lens, 2.8 mm
Focal Length & FOV (2.8 mm): horizontal FOV 105.1°, vertical FOV 54.8°, diagonal FOV 128.2°
Lens Mount: M16
Aperture: F1.0
Supplement Light Type: IR
Supplement Light Range: Up to 80 m (4I model)
IR Wavelength: 850 nm
Video Compression (Main Stream): H.265/H.264/H.264+/H.265+
Video Compression (Sub-stream): H.265/H.264/MJPEG
Video Compression (Third stream): H.265/H.264
Main Stream Frame Rate (50 Hz): 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Main Stream Frame Rate (60 Hz): 24 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream Frame Rate (50 Hz): 25 fps (1280 × 720, 640 × 480, 640 × 360)
Sub-Stream Frame Rate (60 Hz): 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream Frame Rate (50 Hz): 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Third Stream Frame Rate (60 Hz): 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Audio: Built-in microphone (DS-2CD2T86G2H-IS2U/S model, check specific SKU)
Power Method: 12 VDC, PoE (802.3af)
Max Power Consumption: 12 W (PoE), 10 W (12 VDC)
Ingress Protection: IP67
Dimensions: 286.7 × 93.3 × 91.2 mm
Weight: Approx. 1180 g
-
