Samsung 35E 18650
SKU:INR18650-35E
Manufacturer:Samsung
The Samsung INR18650-35E is a high-capacity 18650 lithium-ion cylindrical cell from Samsung SDI, engineered to provide reliable power and extended runtime for various electronic devices.
Key Features
- High Capacity: Offers a typical capacity of 3450 mAh (minimum 3350 mAh) for prolonged operation.
- Nominal Voltage: Operates at a stable 3.6V.
- Discharge Current: Supports a maximum continuous discharge current of 8A.
- Terminal Type: Features a flat positive contact (Flat Top).
- Chemistry: Utilizes LiNiCoAlO2 for efficient and stable performance.
- Unprotected Cell: This is an unprotected cell, requiring integration into devices or battery packs with appropriate protection circuitry.
Applications
Ideal for devices and custom battery assemblies where stable performance and long service life are critical, including:
- Laptops
- Power tools
- E-bikes
- Flashlights
- Custom battery packs
Key Features
- High Capacity: Offers a typical capacity of 3450 mAh (minimum 3350 mAh) for prolonged operation.
- Nominal Voltage: Operates at a stable 3.6V.
- Discharge Current: Supports a maximum continuous discharge current of 8A.
- Terminal Type: Features a flat positive contact (Flat Top).
- Chemistry: Utilizes LiNiCoAlO2 for efficient and stable performance.
- Unprotected Cell: This is an unprotected cell, requiring integration into devices or battery packs with appropriate protection circuitry.
Applications
Ideal for devices and custom battery assemblies where stable performance and long service life are critical, including:
- Laptops
- Power tools
- E-bikes
- Flashlights
- Custom battery packs
Model: INR18650-35E
Manufacturer: Samsung SDI
Form Factor: 18650
Chemistry: Li-ion (LiNiCoAlO2)
Nominal Voltage: 3.6V
Charging Voltage: 4.2V
Typical Capacity: 3450mAh
Minimum Capacity: 3350mAh
Standard Charge Current: 1700mA
Maximum Charge Current: 2000mA
Maximum Continuous Discharge Current: 8A
Maximum Pulse Discharge Current: 13A (не для непрерывного разряда)
Discharge Cut-off Voltage: 2.5V
Internal Resistance: ≤ 35mΩ (AC 1kHz)
Positive Terminal: Flat Top
Diameter: 18.55mm ± 0.1
Height: 65.25mm ± 0.15
Weight: 49g ± 1g
Operating Temperature (Charge): 0 to 45°C
Operating Temperature (Discharge): -10 to 60°C
Manufacturer: Samsung SDI
Form Factor: 18650
Chemistry: Li-ion (LiNiCoAlO2)
Nominal Voltage: 3.6V
Charging Voltage: 4.2V
Typical Capacity: 3450mAh
Minimum Capacity: 3350mAh
Standard Charge Current: 1700mA
Maximum Charge Current: 2000mA
Maximum Continuous Discharge Current: 8A
Maximum Pulse Discharge Current: 13A (не для непрерывного разряда)
Discharge Cut-off Voltage: 2.5V
Internal Resistance: ≤ 35mΩ (AC 1kHz)
Positive Terminal: Flat Top
Diameter: 18.55mm ± 0.1
Height: 65.25mm ± 0.15
Weight: 49g ± 1g
Operating Temperature (Charge): 0 to 45°C
Operating Temperature (Discharge): -10 to 60°C
