MEAN WELL - IRM-02-3.3 - POWER SUPPLY, AC-DC, 3.3V, 0.6A
SKU:2815480
New
Image is for illustrative purposes only
The Mean Well IRM-02-3.3 is a high-quality encapsulated AC-DC power supply designed for direct PCB mounting. Its miniature size (33.7x22.2x15 mm) makes it an ideal choice for compact electronic devices where space is a premium.
This single-output power supply provides a stable 3.3Vdc output with a maximum current of 0.6A, delivering up to 2W of power. One of its standout features is the wide input voltage range of 85-305Vac, allowing for global compatibility across various electrical grids. Built for reliability, it comes with a 36-month warranty, ensuring long-term performance for your industrial or household applications.
This single-output power supply provides a stable 3.3Vdc output with a maximum current of 0.6A, delivering up to 2W of power. One of its standout features is the wide input voltage range of 85-305Vac, allowing for global compatibility across various electrical grids. Built for reliability, it comes with a 36-month warranty, ensuring long-term performance for your industrial or household applications.
Brand: Mean Well
Series: IRM-02
Dimensions LxWxH (mm): 33.7x22.2x15 mm
Width product (mm): 22.2
Height product (mm): 15
Gross weight: 20 g
Warranty: 36 Months Bring-In
Type: AC-DC
Form factor: Encapsulated
Mounting method: PCB Mount
Min. output voltages (V): 3.3
Max. output voltage (V): 3.3
Number of output voltages: 1
Max output power (W): 2
Input voltage (V): 85 - 305
Min. input voltage: 85
Max. input voltage (V): 305
Max. output current (A): 0.6
Number of output currents: 1
IP rating: No IP assigned
LED driver: No
Dimming technologies: No Dimming
Control signals: No control signal
Carbon footprint (kgCO2e/pcs): 0.43
