Voltage converter PNI CN5 input 24V output 12V current 5A
SKU:PNI-CN5
New
Image is for illustrative purposes only
The PNI CN5 is a compact step-down voltage converter designed to transform a 24V DC input into a stable 12V DC output. It provides a reliable power solution for sensitive electronics in heavy-duty vehicle environments.
Key Features
- Wide input range: Accommodates 15V to 32V DC inputs, providing a nominal 13.8V output.
- Power capacity: Supports a continuous current of up to 5A with a maximum power output of 69W.
- High signal quality: Engineered with low electrical noise and minimal ripple to protect sensitive electronic components.
- Robust design: Built to operate across a wide temperature range for consistent performance in various climatic conditions.
Applications
The PNI CN5 is specifically suited for use in trucks, buses, and specialized machinery. Its clean power delivery and low interference make it ideal for powering CB radio stations and other precision electronic devices that require high-quality, stable power.
Key Features
- Wide input range: Accommodates 15V to 32V DC inputs, providing a nominal 13.8V output.
- Power capacity: Supports a continuous current of up to 5A with a maximum power output of 69W.
- High signal quality: Engineered with low electrical noise and minimal ripple to protect sensitive electronic components.
- Robust design: Built to operate across a wide temperature range for consistent performance in various climatic conditions.
Applications
The PNI CN5 is specifically suited for use in trucks, buses, and specialized machinery. Its clean power delivery and low interference make it ideal for powering CB radio stations and other precision electronic devices that require high-quality, stable power.
Compatibility: PNI Escort HP 6500, HP 6500 PRO, HP 6550, HP 7120
Input voltage: 15-32V DC
Maximum output current: 5A
Maximum output power: 69W
Operating temperature: -26°C ~ +80°C
Output voltage: 13.8V DC
Ripple and noise: < 120 mVp-p
Voltage regulation accuracy: ± 3%
Input voltage: 15-32V DC
Maximum output current: 5A
Maximum output power: 69W
Operating temperature: -26°C ~ +80°C
Output voltage: 13.8V DC
Ripple and noise: < 120 mVp-p
Voltage regulation accuracy: ± 3%
-
