Converter 12V->230V 600W modified sine wave
SKU:PIMS600W12
Manufacturer:Nedis
Image is for illustrative purposes only
This power converter is designed for reliable power conversion.
Key Features:
Input Voltage: 12V DC
Output Voltage: 230V AC
Output Waveform: Square wave
Compatibility: Suitable for most devices requiring 230VAC
Maximum Continuous Power: 600W
Peak Power: 1200W
Motor Starting Power: Can provide up to 6x the nominal power for electric motor starting torque.
Important Note: Not suitable for electric motors or starting devices with a nominal power exceeding 200W.
Key Features:
Input Voltage: 12V DC
Output Voltage: 230V AC
Output Waveform: Square wave
Compatibility: Suitable for most devices requiring 230VAC
Maximum Continuous Power: 600W
Peak Power: 1200W
Motor Starting Power: Can provide up to 6x the nominal power for electric motor starting torque.
Important Note: Not suitable for electric motors or starting devices with a nominal power exceeding 200W.
Input Voltage: 10-15VDC
Maximum Current Draw: 60A
Converter Standby Consumption:
Output Voltage: 230VAC
Frequency: 50Hz
Rated Output Power: 600W
Peak Power: 1200W
Efficiency: 85~90%
Low Input Voltage Warning: 10.5+/-0.5VDC
Low Input Voltage Shutdown: 10+/-0.5VDC
Temperature Protection: 60+/-5°C
Overload Protection: Microcontroller controlled
Short Circuit Protection: Microcontroller controlled
Input Overvoltage Protection: Microcontroller controlled
Reverse Polarity Protection: Fuse
Fuse: 3x30A
Dimensions: 213*200*70mm
Weight: 2000g
Maximum Current Draw: 60A
Converter Standby Consumption:
Output Voltage: 230VAC
Frequency: 50Hz
Rated Output Power: 600W
Peak Power: 1200W
Efficiency: 85~90%
Low Input Voltage Warning: 10.5+/-0.5VDC
Low Input Voltage Shutdown: 10+/-0.5VDC
Temperature Protection: 60+/-5°C
Overload Protection: Microcontroller controlled
Short Circuit Protection: Microcontroller controlled
Input Overvoltage Protection: Microcontroller controlled
Reverse Polarity Protection: Fuse
Fuse: 3x30A
Dimensions: 213*200*70mm
Weight: 2000g
-
