BD80TW In/Outdoor Speaker IPX5 White 100V

SKU:TR952.138OS
BD80TW In/Outdoor Speaker IPX5 White 100V
Image is for illustrative purposes only

The BD 100V Indoor/Outdoor Speaker Series are engineered and tuned to offer weatherproof construction, excellent sound quality and supreme flexibility. This Series speakers is featured with a high end two-way system; a 1.1” silk-dome tweeter and a polypropylene 8” bass/midrange driver. The low-frequency output is bolstered by the use of a rear-mounted bass radiator. OBE technology (Optimal Bass Enhancement Radiator) provides deep and clear bass thanks to this passive cone. These enclosures are ideal for outdoor events, swimming pools, garden areas and marine or boat use. Adjustable between 70V, 100V tappings or 8 Ohm operation via rotary switch. You can mount the speakers to the wall horizontally or vertically with the included mounting kit.

Brand: Power Dynamics
Speaker type: Passive (non-amplified)
Product colour: White
Output power: RMS: 80W
Tweeter type: Dome
Diameter tweeter: 1.1"
Diameter woofer: 8"
Magnet type: Ferrite
Impedance: 8 Ohm, 70V, 100V
Tappings power (100V): 6.25W, 12.5W, 25W, 50W
Tappings power (70V): 3.75W, 6.25W, 12.5W, 25W
Frequency response: 60 Hz - 20.000 Hz
SPL @ 1W/1m: 96dB
IP rating: IPX5
Operating temperature: -20 °C ~ 60 °C
Dimensions (L x W x H): 250 x 250 x 381mm
Weight (kg): 5
Included accessories: Mounting bracket
952.138_952.140 BD80T Speaker 100V_manual_V1.1.pdf
Download
