TT02-PT1000B-1D-T105-1500 Temperature Sensor
SKU:TT02PT1000B1DT105
New
The TEWA TT02-PT1000B-1D-T105-1500 is a high-precision Pt1000 platinum resistance thermometer designed for reliable temperature monitoring in demanding environments.
Key Features
- Employs overmoulding technology to hermetically encapsulate the sensor and cable in a unified black thermoplastic elastomer (TPE) housing.
- Provides an IP68 protection rating for reliable performance in high humidity, direct liquid contact, and freeze-thaw cycles.
- Features a compact probe design with a 5 mm diameter and 20 mm length for easy integration into various systems.
- Utilizes a high-accuracy Pt1000 platinum sensing element for stable and precise measurements.
Applications
The sensor's robust construction and moisture resistance make it ideal for use in climate control (HVAC) systems, commercial refrigeration equipment, and various industrial process installations where protection against the elements is critical.
Key Features
- Employs overmoulding technology to hermetically encapsulate the sensor and cable in a unified black thermoplastic elastomer (TPE) housing.
- Provides an IP68 protection rating for reliable performance in high humidity, direct liquid contact, and freeze-thaw cycles.
- Features a compact probe design with a 5 mm diameter and 20 mm length for easy integration into various systems.
- Utilizes a high-accuracy Pt1000 platinum sensing element for stable and precise measurements.
Applications
The sensor's robust construction and moisture resistance make it ideal for use in climate control (HVAC) systems, commercial refrigeration equipment, and various industrial process installations where protection against the elements is critical.
Sensor type: Pt1000 (Platinum resistance thermometer)
Nominal resistance: 1000 Ω (at 0°C)
Accuracy class: B (cl.B)
Operating temperature range: -40°C ... +105°C
Housing (probe) dimensions: Ø5 x 20 mm
Protection rating: IP68 (full tightness)
Cable length: 1500 mm (1.5 m)
Cable type: 2x AWG24, stranded, tinned copper
Cable and housing insulation: TPE (Thermoplastic elastomer)
Insulation voltage: 1500V DC
Terminal configuration: 2-wire
Nominal resistance: 1000 Ω (at 0°C)
Accuracy class: B (cl.B)
Operating temperature range: -40°C ... +105°C
Housing (probe) dimensions: Ø5 x 20 mm
Protection rating: IP68 (full tightness)
Cable length: 1500 mm (1.5 m)
Cable type: 2x AWG24, stranded, tinned copper
Cable and housing insulation: TPE (Thermoplastic elastomer)
Insulation voltage: 1500V DC
Terminal configuration: 2-wire
-
