Button OFF-(ON) 250V 2A metall 19/22mm
SKU:R1500A
Image is for illustrative purposes only
Button OFF-(ON) 250V 2A metall 19/22mm
| anti-vandal | |||
| type: OFF-(ON) SPST | |||
| ratings: 250Vac / 5A | |||
| contacts: off-(on) silver | |||
| material: brass nickel | |||
| contact resistance: 35mohm max. | |||
| insulation resistance: 500Vdc 100Mohm min. | |||
| dielectric strength: 1 min. 1000Vac | |||
| electrical life: 50000 cycles | |||
| drill Ø: 19mm | |||
| dielectrical strength: 1500Vac | |||
| contact resistance: 20mohm max. | |||
| electrical life: 50000 min. | |||
| insulation resistance: 100Mohm | |||
| mechanical life: min. 100000 actuations |
-
