SKU:MP0042/1
Image is for illustrative purposes only
Manufacturer Part Number: MP0042/1
Brand: Bulgin
Mounting Type: Panel Mount
Switch Mode: Momentary (OFF-(ON))
Contact Configuration: SPST
Current Rating: 2A
Voltage Rating: 48VDC
Actuator Type: Flush, Round
Housing Material: Stainless Steel (Polished)
Diameter: 16mm
Connection: Screw Terminals
IP Rating: IP65
Operating Temperature Range: -20 to +55°C
The Bulgin MP0042/1 button is a vandal-resistant push-button switch with a flush profile, designed for use in conditions requiring high resistance to wear, corrosion, and rough handling.
Made from polished stainless steel, this switch has a diameter of 16 mm and offers momentary action (OFF-(ON)).
It is equipped with screw terminals and has an IP65 protection rating, making it suitable for use in public places, industrial environments, and building automation systems.
The switch is rated for 2A current at 48VDC and operates within a temperature range of -20°C to +55°C.
Brand: Bulgin
Mounting Type: Panel Mount
Switch Mode: Momentary (OFF-(ON))
Contact Configuration: SPST
Current Rating: 2A
Voltage Rating: 48VDC
Actuator Type: Flush, Round
Housing Material: Stainless Steel (Polished)
Diameter: 16mm
Connection: Screw Terminals
IP Rating: IP65
Operating Temperature Range: -20 to +55°C
The Bulgin MP0042/1 button is a vandal-resistant push-button switch with a flush profile, designed for use in conditions requiring high resistance to wear, corrosion, and rough handling.
Made from polished stainless steel, this switch has a diameter of 16 mm and offers momentary action (OFF-(ON)).
It is equipped with screw terminals and has an IP65 protection rating, making it suitable for use in public places, industrial environments, and building automation systems.
The switch is rated for 2A current at 48VDC and operates within a temperature range of -20°C to +55°C.
Actuator Marking: No Marking
Actuator Type: Flush, Round Button
Actuator/Cap Color: Silver
Contact Configuration: SPST-NO
Electrical Life: 100,000 cycles
Features: Stainless Steel, Vandal Resistant
Housing Material: Polished Stainless Steel
IP Rating: IP65
Manufacturer: Bulgin
Max Contact Current: 2 A
Mechanical Life: 1,000,000 cycles
Operating Temperature Range: -20°C ~ 55°C
Panel Cutout Dimensions: 16.2 mm Dia
Switch Action: Momentary (OFF-(ON))
Switch Type: Pushbutton Switch
Termination Type: Screw Terminal
Actuator Type: Flush, Round Button
Actuator/Cap Color: Silver
Contact Configuration: SPST-NO
Electrical Life: 100,000 cycles
Features: Stainless Steel, Vandal Resistant
Housing Material: Polished Stainless Steel
IP Rating: IP65
Manufacturer: Bulgin
Max Contact Current: 2 A
Mechanical Life: 1,000,000 cycles
Operating Temperature Range: -20°C ~ 55°C
Panel Cutout Dimensions: 16.2 mm Dia
Switch Action: Momentary (OFF-(ON))
Switch Type: Pushbutton Switch
Termination Type: Screw Terminal
