Thermal Camera Hikmicro FB21 256x192 IP65

SKU:HM-HM-TF52-3AQF-FB21
Manufacturer:Hikmicro
Thermal Camera Hikmicro FB21 256x192 IP65
Image is for illustrative purposes only
The Hikmicro FB21 is a specialized, compact handheld thermal camera designed specifically for firefighting and rescue operations. This rugged tool is engineered to provide clear visibility in total darkness and smoke-filled environments, making it an essential companion for first responders navigating hazardous conditions.

Equipped with a high-resolution 256 × 192 thermal sensor and a 2 MP visual camera, the FB21 offers multiple image modes including Thermal, Visual, Fusion, and Picture-in-Picture. This versatility allows users to identify hotspots and structural details with exceptional clarity. The device features specialized color palettes like Fire Detection and Rescue, which are optimized to highlight critical heat signatures and life-signs during time-sensitive missions.

Durability is at the core of the FB21's design. It boasts an IP65 protection rating and has been tested to withstand drops from up to 2 meters. Crucially for firefighting, it is built to endure extreme heat, remaining operational at 90°C for up to 10 minutes and even 115°C for 2 minutes. With a battery life of approximately 6 hours and a fast 3-hour charging time, the Hikmicro FB21 ensures reliability when every second counts.
Infrared Resolution: 256 × 192 (49,152 pixels)
NETD: < 40 mK (@ 25 °C, F#=1.0)
Image Frequency: 25 Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 to 14 μm
Focal Length: 3.6 mm
F-number: F1.0
Field of View (FOV): 37.2° × 50.0°
Spatial Resolution (IFOV): 3.3 mrad
Focus Mode: Focus Free
Min. Focus Distance: 0.3 m (0.98 ft)
Visual Camera: 1600 × 1200 (2 MP)
Display: 240 × 320 Resolution, 3.2” LCD Screen
Image Modes: Thermal/Visual/Fusion/PIP
Color Palettes: Basic, Black Hot, White Hot, Fire Detection, Rescue, Hot Area, Cold Area, Building
Color Alarm: Above alarm
Object Temperature Range: -20°C to 150°C and 100°C to 550°C
Accuracy: Max. (± 2°C/3.6°F, ± 2%)
Measurement Tools: Center Spot, Hot Spot, Cold Spot; User-definable: 3 spots
Storage Media: Built-in 16 GB flash memory (Approx. 90,000 Images)
USB Interface: USB Type-C
Battery Type: Rechargeable Li-ion battery
Battery Operating Time: Approx. 6 hours
Battery Charging Time: Approx. 3 hours fully charged
Protection Level: IP65
Drop Test Height: 2 m (6.56 ft)
Working Temperature Range: -10°C to 50°C (14°F to 122°F)
High Temperature Resistance: 90°C (10min), 115°C (2min)
Weight: Approx. 380 g (0.84 lb)
Dimension: 221.7 × 73.5 × 123.8 mm
LED Light: Yes
HM-HM-TF52-3AQF-FB21 Manual EN744.28KB
Download
