DC/DC step-up power module 3..25V/4..28V 2A, USB-C input

The MOD-2344 is a highly efficient DC/DC step-up power module, expertly designed to elevate voltage levels for a wide array of electronic applications. It provides a reliable solution for boosting voltage with ease and precision.

General Information

The MOD-2344 accepts a DC input voltage ranging from 3V to 25V and provides a regulated DC output voltage ranging from 4V to 28V with a rated current of 2A. It features a USB-C input for convenient power connectivity.

Key Features

- Wide Input Voltage Range: Accepts input voltages from 3V to 25V DC.

- Adjustable Output Voltage: Provides adjustable output voltages from 4V to 28V DC.

- Output Current: Delivers a rated output current of 2A.

- USB-C Input: Equipped with a USB-C input connector for easy power connection.

Ideal Applications and Benefits

- Portable Electronics: Perfectly suited for powering portable devices that require higher voltage levels than the available battery voltage.

- DIY Projects: An excellent choice for various DIY electronics projects where a stable and adjustable voltage source is essential.

- Powering LED Lighting: Can be effectively used to power LED lighting systems that require a specific voltage range.

- Battery Charging: Can be seamlessly incorporated into battery charging circuits to provide the necessary voltage for charging different battery types.
