To combat interference, the G106 includes specialized digital CW filters with three adjustable bandwidths, making weak signal reception much more manageable. The transceiver is ready for digital modes like FT8 when paired with the optional DE-19 adapter. Whether you are operating SSB, CW, or digital, this user-friendly and computer-controllable unit serves as an excellent entry point into the world of portable HF radio.
RX frequency range: 0.55~30MHz, 88~108MHz (WFM)
TX frequency range: 3.5~3.9MHz, 7.0~7.2MHz, 10.1~10.15MHz, 14.0~14.35MHz, 18.068~18.168MHz, 21.0~21.45MHz, 24.89~24.99MHz, 28.0~29.7MHz
Operating mode: SSB/CW/AM, WFM (receive only)
Receiving sensitivity: CW: 0.25uV @10dB S/N, SSB: 0.5uV @10dB S/N, AM: 10uV @10dB S/N
Frequency stability: ±1.5ppm within 30min after power on, @25°C: 1ppm/hour
Transmitting power: ≥5W @13.8V DC
Transmitting spurious suppression: ≥50dB
Audio output power: 0.3W
Operating voltage: 9~15V DC
Standby current: 0.37A @Max
Transmitting current: 2.8A @Max
Dimensions: 120x40x135 (mm)
Weight: About 720g (radio unit)
In the Box: G106 radio unit
Hand microphone with speaker
12 Volt DC power cord
English manual
Xiegu Warranty Card
Xiegu Quality certificate
Declaration of conformity
-
