Test probe with insulated sleeve, socket: 4mm (PRUEF2600 red)

Test probe with elastic, shatterproof insulating sleeve and thin, stainless spring steel tip. This ensures a constant pressure without the probe slipping off, even on the smallest measuring points. Connects with 4mm standard laboratory equipment and safety laboratory equipment.
SpecificationsProduct basic info
Primary colours: Red
Additional colours: Grey
Width unit: 9.4 cm
Weight unit: 6.4 g
Material: Polypropylene
Additional material: Brass
Physical properties
Tip shape: Pointed
Tip material: Nickel, Stainless steel
Tip size: 2 mm
Shaft diameter: 4.3 mm
Socket size: 4 mm
Handle diameter: 13 mm
Depth shaft: 90 mm
Electrical data
Current rating: 1 A
Contact resistance: 50 milliohm
Technical data
Flammability rating: UL 94 HB
Measurement category: III
Environmental data
Operating temperature range: -25-80 °C
Operational properties
Contact type: Unsprung tip
Electrical connections
Gender: Female
Termination type: Unsprung socket
IT connections
Connection type: Socket
Power supply
Voltage rating VDC: 1000 V
Voltage rating VAC: 1000 V AC
