SKU:ANT0634
Cabletech "Yagi" Active Directional TV Antenna The Cabletech external "Yagi" directional TV antenna is a device that allows you to receive terrestrial digital television DVB-T and DVB-T2 from long distances, even in difficult terrain with high interference. The antenna operates in the VHF 174-230 MHz and UHF 470-790 MHz bands, guaranteeing proper reception of a high-quality signal, so you can enjoy excellent picture and sound of your favorite series or movies.
Strong Signal Moreover, thanks to VHF band support, the Cabletech antenna enables reception of terrestrial digital television channels located on the MUX 8 multiplex. The LTE filter used in this model eliminates LTE network interference, which affects the quality of the terrestrial television signal. The antenna has a gain of up to 23 dB.
Durability and Reliability The solid construction makes it not only easy to install, but above all guarantees long-lasting, stable operation in all weather conditions.
Strong Signal Moreover, thanks to VHF band support, the Cabletech antenna enables reception of terrestrial digital television channels located on the MUX 8 multiplex. The LTE filter used in this model eliminates LTE network interference, which affects the quality of the terrestrial television signal. The antenna has a gain of up to 23 dB.
Durability and Reliability The solid construction makes it not only easy to install, but above all guarantees long-lasting, stable operation in all weather conditions.
Frequency range: (VHF) 174-230 MHz, (UHF) 470-790 MHz
Range: DVB-T / DVB-T2 / DAB+
Channels: 5-12; 21-60
Impedance: 75 Ohm
Number of elements: 16
Gain: (VHF) 20 dB, (UHF) 25 dB
Front-to-back ratio: 23 dB
Beamwidth H / V: +/-15°
Polarization: horizontal
Antenna length: 94 cm
LTE filter: yes
Included: waterproof connector, F connector, amplifier, power supply
----------
External amplifier
----------
Gain (of amplifier): 20 dB
Noise figure: < 3.5 dB
Power supply:
- Input: 100-230 V AC
- Output: 5 V DC / 550 mA
Range: DVB-T / DVB-T2 / DAB+
Channels: 5-12; 21-60
Impedance: 75 Ohm
Number of elements: 16
Gain: (VHF) 20 dB, (UHF) 25 dB
Front-to-back ratio: 23 dB
Beamwidth H / V: +/-15°
Polarization: horizontal
Antenna length: 94 cm
LTE filter: yes
Included: waterproof connector, F connector, amplifier, power supply
----------
External amplifier
----------
Gain (of amplifier): 20 dB
Noise figure: < 3.5 dB
Power supply:
- Input: 100-230 V AC
- Output: 5 V DC / 550 mA
