Adafruit ALS-PT19 Analog Light Sensor Breakout

Tootekood:ADA2748
Adafruit ALS-PT19 Analog Light Sensor Breakout
Pilt on illustratiivne

Add a teeny analog light sensor, the ALS PT19 analog light sensor is a great way to upgrade a project that uses a photocell and needs RoHS compliance. Due to the high rejection ratio of infrared radiation, the spectral response of the ambient light sensor is close to that of human eyes.

It's a pretty simple sensor - connect - to ground, + to 2.5V-5.5V or so to power it. Now measure the analog voltage on the OUT pin. That's it! The voltage will increase when the sensor detects more light.

Manufacturer

ADAFRUIT

Type of sensor

ambient light

Interface

analog

Supply voltage

2.5...5.5V DC

Integrated circuit

ALS-PT19

Number of channels

1

Mounting

screw

Information

product is not a working device, but only component
