FNIRSI® DS215H 2-IN-1 50MHz 250MS/s Dual Channel Digital Oscilloscope DDS Function Singal Generator
SKU:FNIRSI DS215H
Manufacturer:FNIRSI
New
Image is for illustrative purposes only
The FNIRSI DS215H is a versatile 2-in-1 portable digital measuring device, combining a 50 MHz digital oscilloscope and a DDS signal generator.
Designed with an FPGA+MCU+ADC hardware architecture, it is ideal for technical maintenance, research, and development applications.
Key Features
- Dual Functionality: Integrates a 50 MHz digital oscilloscope and a DDS signal generator in one portable unit.
- High Performance Oscilloscope: Offers a 250 MSa/s real-time sampling rate and 50 MHz analog bandwidth for precise measurements.
- Wide Voltage Measurement: Safely measures peak voltages up to ±400 V.
- Waveform Storage: Supports saving and viewing waveform screenshots for detailed data analysis.
- Versatile Signal Generator: Provides 13 adjustable output waveforms with a 0-50 kHz frequency range (1 Hz step), adjustable amplitude (0.1V-3.0V), and duty cycle (0-100%).
- Clear Display: Features a 3.5-inch 480x320 high-resolution IPS color display.
- Portable Design: Compact (approx. 66x110x19.5 mm) and lightweight (138 g) for easy transport and mobile use.
- Extended Operation: Powered by a 1500 mAh rechargeable lithium battery, providing up to 4 hours of continuous use, charged via USB Type-C (5V/1A).
- Multi-language Interface: Supports multiple languages for enhanced user convenience.
Designed with an FPGA+MCU+ADC hardware architecture, it is ideal for technical maintenance, research, and development applications.
Key Features
- Dual Functionality: Integrates a 50 MHz digital oscilloscope and a DDS signal generator in one portable unit.
- High Performance Oscilloscope: Offers a 250 MSa/s real-time sampling rate and 50 MHz analog bandwidth for precise measurements.
- Wide Voltage Measurement: Safely measures peak voltages up to ±400 V.
- Waveform Storage: Supports saving and viewing waveform screenshots for detailed data analysis.
- Versatile Signal Generator: Provides 13 adjustable output waveforms with a 0-50 kHz frequency range (1 Hz step), adjustable amplitude (0.1V-3.0V), and duty cycle (0-100%).
- Clear Display: Features a 3.5-inch 480x320 high-resolution IPS color display.
- Portable Design: Compact (approx. 66x110x19.5 mm) and lightweight (138 g) for easy transport and mobile use.
- Extended Operation: Powered by a 1500 mAh rechargeable lithium battery, providing up to 4 hours of continuous use, charged via USB Type-C (5V/1A).
- Multi-language Interface: Supports multiple languages for enhanced user convenience.
Automatic Measurements: Cycle, Freq, Vpp, Max, Min, Avg, RMS, Amp, Duty cycle, Pulse width
Bandwidth: 50 MHz
Battery Capacity: 1500mAh
Channels: Dual channel
Display: 3.5 inches IPS high-definition color screen (480x320 resolution)
Input Coupling: AC / DC
Input Impedance: 1MΩ
Languages: 中文, English, Deutsch, Português, 日本語, Español, 한국인, Pyccкий
Max Input Voltage: ±400V
Power Supply: TYPE-C (5V/1A)
Probe Attenuation Ratio: 1x / 10x
Product Size: ≈66x110x19.5 mm
Product Weight: ≈138 g
Real-time Sampling Rate: 250 MSa/s
Signal Generator Amplitude: 0.1V - 3.0V
Signal Generator Duty Cycle: 0-100%
Signal Generator Frequency Range: 0-50 KHz (1Hz step)
Signal Generator Waveform Types: 13 types
Storage Depth: 14M
Time Base Range: 20ns/div - 20s/div
Trigger Level Range: 8 grids (positive and negative)
Trigger Mode: Auto / Normal / Single
Trigger Type: Rising Edge / Falling Edge
Vertical Resolution: 8 bits
Vertical Sensitivity: 10mV/div - 10V/div
Waveform Display Mode: Scroll
Bandwidth: 50 MHz
Battery Capacity: 1500mAh
Channels: Dual channel
Display: 3.5 inches IPS high-definition color screen (480x320 resolution)
Input Coupling: AC / DC
Input Impedance: 1MΩ
Languages: 中文, English, Deutsch, Português, 日本語, Español, 한국인, Pyccкий
Max Input Voltage: ±400V
Power Supply: TYPE-C (5V/1A)
Probe Attenuation Ratio: 1x / 10x
Product Size: ≈66x110x19.5 mm
Product Weight: ≈138 g
Real-time Sampling Rate: 250 MSa/s
Signal Generator Amplitude: 0.1V - 3.0V
Signal Generator Duty Cycle: 0-100%
Signal Generator Frequency Range: 0-50 KHz (1Hz step)
Signal Generator Waveform Types: 13 types
Storage Depth: 14M
Time Base Range: 20ns/div - 20s/div
Trigger Level Range: 8 grids (positive and negative)
Trigger Mode: Auto / Normal / Single
Trigger Type: Rising Edge / Falling Edge
Vertical Resolution: 8 bits
Vertical Sensitivity: 10mV/div - 10V/div
Waveform Display Mode: Scroll
-
